2004 Shadow VT125C
Engine |
|
| Engine Type | Liquid-cooled 4-stroke 4-valve SOHC 90° V-twin |
| Displacement | 125cc |
| Bore and Stroke | 42 x 45mm |
| Compression Ratio | 11.8:1 |
| Fuel Delivery | 22mm VP-type x 2 |
| Ignition | Digital transistorised with electronic advance |
| Max. Power Output | 15 bhp at 11,000 rpm |
| Max. Torque | 10.5Nm at 9,000 rpm |
DRIVETRAIN |
|
| Transmission | 5-speed |
| Final Drive | Roller chain |
CHASSIS / SUSPENSION / BRAKES |
N/A |
DIMENSION |
|
| Seat Height | 680mm |
| Wheelbase | 1,530mm |
| Dry Weight | 145kg |
| Fuel Capacity | 14 litres (including 2.1 litre reserve) |
| Ground Clearance | 145mm |
OTHER |
2007 VT125C SHADOW
Engine |
|
| Engine Type | Liquid-cooled 4-stroke 4-valve SOHC 90° V-twin |
| Displacement | 125cc |
| Bore and Stroke | 42 x 45mm |
| Compression Ratio | 11.8:1 |
| Fuel Delivery | 22mm VP-type x 2 |
| Ignition | Digital transistorised with electronic advance |
| Max. Power Output | 15 bhp at 11,000 rpm |
| Max. Torque | 10.5Nm at 9,000 rpm |
DRIVETRAIN |
|
| Transmission | 5-speed |
| Final Drive | Roller chain |
CHASSIS / SUSPENSION / BRAKES |
N/A |
| Front Suspension | 35mm telescopic fork, 110mm axle travel |
| Rear Suspension | Dual dampers with adjustable preload, 80mm axle travel |
| Front Brakes | 240mm hydraulic disc with dual-piston caliper |
| Rear Brakes | 130mm leading/trailing drum |
| Front Tire | 110/90-17 (55P) |
| Rear Tire | 130/90-15M/C (66P) |
DIMENSION |
|
| Length x Width x Height | 2,300 x 890 x 1,110mm |
| Seat Height | 680mm |
| Wheelbase | 1,530mm |
| Dry Weight | 145kg |
| Fuel Capacity | 14 litres (including 2.1 litre reserve) |
| Ground Clearance | 145mm |
OTHER |
