2004 Transalp XL650V
| Engine Type | Liquid-cooled 4-stroke 6-valve SOHC 52° V-twin |
| Bore and Stroke | 79 x 66mm |
| Displacement | 644cc |
| Compression Ratio | 9.2:1 |
| Fuel Delivery | 34mm slant-type CV x 2 |
| Max. Power Output | 52 bhp at 7,500 rpm |
| Max. Torque | 55Nm at 3,500 rpm |
| Ignition | Digital transistorised with electronic advance |
| Starter | Electric |
| Transmission | 5-speed |
| Final Drive | ‘O’-Ring sealed chain |
| Length x Width x Height | 2,260 x 920 x 1,315mm |
| Wheelbase | 1,505mm |
| Seat Height | 843mm |
| Ground Clearance | 192mm |
| Fuel Capacity | 19 litres (including 3 litre reserve) |
| Dry Weight | 191kg |
| Front Wheel | 21 x 1.85 aluminum rim/wire spoke |
| Rear Wheel | aluminum rim/Tangentially Located (TL) spokes |
| Front Tire | 90/90-21 (54S) |
| Rear Tire | 120/90-17 (64S) |
- Front Suspension: 41mm leading-axle fork, 220mm axle travel
- Rear Suspension: Pro-Link with adjustable compression damping, 172mm axle travel
- Front Brakes: 256mm dual hydraulic disc with dual-piston calipers and sintered metal pads
- Rear Brake: s: 240mm hydraulic disc with single-piston caliper and resin mould pads
2007 XL650V TRANSALP
| Engine Type | Liquid-cooled 4-stroke 6-valve SOHC 52° V-twin |
| Bore and Stroke | 79 x 66mm |
| Displacement | 644cc |
| Compression Ratio | 9.2:1 |
| Fuel Delivery | 34mm slant-type CV x 2 |
| Max. Power Output | 52 bhp at 7,500 rpm |
| Max. Torque | 55Nm at 3,500 rpm |
| Ignition | Digital transistorised with electronic advance |
| Starter | Electric |
| Transmission | 5-speed |
| Final Drive | ‘O’-Ring sealed chain |
| Length x Width x Height | 2,260 x 920 x 1,315mm |
| Wheelbase | 1,505mm |
| Seat Height | 843mm |
| Ground Clearance | 192mm |
| Fuel Capacity | 19 litres (including 3 litre reserve) |
| Dry Weight | 191kg |
| Front Wheel | 21 x 1.85 aluminum rim/wire spoke |
| Rear Wheel | aluminum rim/Tangentially Located (TL) spokes |
| Front Tire | 90/90-21 (54S) |
| Suspension Front | 41mm leading-axle fork, 220mm axle travel |
| Suspension Rear | Pro-Link with adjustable compression damping, 172mm axle travel |
| Brakes Front | 256mm dual hydraulic disc with dual-piston calipers and sintered metal pads |
| Brakes Rear | 240mm hydraulic disc with single-piston caliper and resin mould pads |
