1984 CBX750F
Engine |
|
| Engine Type | In-line four, four-stroke |
| Displacement | 747.00 ccm (45.58 cubic inches) |
| Power | 91.00 HP (66.4 kW)) @ 9500 RPM |
| Top speed | 211.0 km/h (131.1 mph) |
| Compression | 9.3:1 |
| Bore x stroke | 67.0 x 53.0 mm (2.6 x 2.1 inches) |
| Valves per cylinder | 4 |
| Fuel control | DOHC |
| Cooling system | Air |
| Horsepower | 93 hp (69.4 kW) @ 9500 rpm |
| Maximum Torque | 70.6 Nm (52.7 ft. lbs) @ 8500 rpm |
DRIVETRAIN |
|
| Transmission | 6-speed |
| Final Drive | Chain |
CHASSIS / SUSPENSION / BRAKES |
|
| FrontBrake | dual 260 mm discs with 2-piston calipers |
| Rear Brake | single 280 mm disc with 2-piston calipers |
| Front Tire | 110/90-16 |
| Rear Tire | 130/80-18 |
DIMENSION |
|
| Seat Height | 795 mm (31.3 inches) |
| Wheelbase | 1465 mm (57.7 inches) |
| Fuel Capacity | 22 litres (5.8 Gal) including 4 litres (1.1 Gal) reserve |
| Dry weight |
|
