2012 Honda CBF125
Engine |
|
| Engine Type | Air-cooled 4-stroke 2-valve OHC single |
| Displacement | 124.7cc |
| Bore and Stroke | 52.4 x 57.8mm |
| Compression Ratio | 9.2:1 |
| Fuel Delivery | PGM-FI electronic fuel injection |
| Ignition | Computer controlled fully transistorised with electronic advance |
| Max. Power Output | 8.3kW/8,000min-1 |
| Max. Torque | 11.2Nm/6,250min-1 |
| Starter | Electric |
DRIVETRAIN |
|
| Transmission | 5-speed |
| Final Drive | 2.63 |
| Front Wheel | U-cross-section 6-spoke cast aluminium 17M/C x MT1.85 |
| Rear Wheel | U-cross-section 6-spoke cast aluminium 17M/C x MT2.15 |
CHASSIS / SUSPENSION / BRAKES |
|
| Front Suspension | 30mm telescopic fork, 115mm axle travel |
| Rear Suspension | Conventional twin shock, double tube damper with 3-step adjustable spring preload, 87mm axle travel |
| Front Brakes | 240mm hydraulic disc with 2-pod caliper and resin mould pads |
| Rear Brakes | 130mm leading/trailing drum |
| Front Tire | 80/100-17M/C (46P) |
| Rear Tire | 100/90-17M/C (55P) |
DIMENSION |
|
| Seat Height | 792mm (31.2 inches) |
| Wheelbase | 1270mm (50 inches) |
| Curb Weight | 128 kg (282 lb) |
| Fuel Capacity | 13 Litres (3.4 GalUS) |
| Ground Clearance | 173mm (6.8 inches) |
| Overall Length | 1955mm (77 inches) |
| Overall Width | 760mm (30 inches) |
| Overall Height | 1110mm (43.7 inches) |
| Rear | 81 kg (178 lb) |
OTHER |
No Comment
